4.2 Temperature Controller/Servo/Inverter Connection 4-23
Address denotations
 AHC2001
On the signal name reference list, every group ID is designated as “001”. To access any group ID other than “001”,
manually input the desired ID.
aaabbbcc
 DCP31/32
The address for DCP31/32 is not provided in the signal name reference list. Manually set the address by referring to the
instruction manual for DCP31/32.
---xxxx
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
Return data: Data stored from temperature controller to V series
820 (user-defined area) 31H AHC2001, double-word
E01 (user-defined area) 32H AHC2001, double-word
E02 (user-defined area) 33H AHC2001, double-word
E03 (user-defined area) 34H AHC2001, double-word
E04 (user-defined area) 35H AHC2001, double-word
F01 (user-defined area) 36H AHC2001, double-word
F02 (user-defined area) 37H AHC2001, double-word
F03 (user-defined area) 38H AHC2001, double-word
F04 (user-defined area) 39H AHC2001, double-word
F05 (user-defined area) 3AH AHC2001, double-word
F06 (user-defined area) 3BH AHC2001, double-word
--- (DCP) 3CH DCP31/32
Device Memory (Parameter Type ID) TYPE Remarks
Item ID
Group ID
Parameter type ID
Address 0501 to 4600
Device type
Contents F0 F1 (= $u n) F2
ISaGRAF application
Start/stop
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 0
n + 2
0: Stop
1: Start
ISaGRAF application
Current status
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 1
n + 2
0: Stop
1: Run
Reserve for parameter backup
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 2
