7.1 Temperature Controller/Servo/Inverter Connection 7-1
7.1 Temperature Controller/Servo/Inverter Connection
Digital Temperature Controller
Graphic Recorder
PLC Selection on
the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
DP1000
DP1xxxBRxx Terminal block RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
DP1000.Lst
DP1xxxBAxx Terminal block RS-422 Wiring diagram 1 - C4
DP10xxGRxx-xxx
Terminal
block
COM1 RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
DP10xxGSxx-xxx
Terminal
block
COM1 RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
DP10xxGAxx-xxx
Terminal
block
COM1 RS-422 Wiring diagram 1 - C4
DP10xxGBxx-xxx
Terminal
block
COM1
RS-232C
Wiring diagram 2 - C2 Wiring diagram 2 - M2
COM2 Wiring diagram 3 - C2 Wiring diagram 3 - M2
DP10xxGCxx-xxx
Terminal
block
COM1 RS-485 Wiring diagram 3 - C4 Wiring diagram 2 - M4
COM2 RS-232C Wiring diagram 3 - C2 Wiring diagram 3 - M2
DP10xxGDxx-xxx
Terminal
block
COM1 RS-422 Wiring diagram 4 - C4
COM2 RS-232C Wiring diagram 3 - C2 Wiring diagram 3 - M2
DP10xxGExx-xxx
Terminal
block
COM1 RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
COM2 RS-485 Wiring diagram 5 - C4 Wiring diagram 3 - M4
DP10xxGFxx-xxx
Terminal
block
COM1
RS-485
Wiring diagram 3 - C4 Wiring diagram 2 - M4
COM2 Wiring diagram 5 - C4 Wiring diagram 3 - M4
DP10xxGGxx-xxx
Terminal
block
COM1 RS-422 Wiring diagram 4 - C4
COM2 RS-485 Wiring diagram 5 - C4 Wiring diagram 3 - M4
DB1000B
(MODBUS RTU)
DB1xxxBRxx-xxx
Terminal bloc k
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
DB1000B.LstDB1xxxBAxx-xxx RS-422 Wiring diagram 1 - C4
DB1xxxBSxx-xxx RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
LT230
(MODBUS RTU)
LT23xxxS00-xx
Terminal block RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4 LT230.Lst
LT23xxx200-xx
LT300
(MODBUS RTU)
LT35xxxRx0-xxx
Terminal bloc k
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
LT300.Lst
LT37xxxRx0-xxx
LT35xxxAx0-xxx
RS-422 Wiring diagram 1 - C4
LT37xxxAx0-xxx
LT35xxxSx0-xxx
RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
LT37xxxSx0-xxx
LT400 Series
(MODBUS RTU)
LT45xxxRxx-xxx
Terminal bloc k
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
LT400.Lst
LT47xxxRxx-xxx
LT45xxxAxx-xxx
RS-422 Wiring diagram 1 - C4
LT47xxxAxx-xxx
LT45xxxSxx-xxx RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
LT830
(MODBUS RTU)
LT830xx000-2xx Terminal block RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4 LT830.Lst
PLC Selection on
the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
KR2000
(MODBUS RTU)
KR21xxxRxA Terminal block
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
KR2000.Lst
RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
KR21xxxQxA Terminal block
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
RS-485 Wiring diagram 2 - C4 Wiring diagram 1 - M4
