8-6 8. CIMON
CM1-SC01A, CM1-SC01B, CM1-SC02A (CH1)
Make communication settings using the application software “CICON”. For more information, refer to the instruction manual
issued by CIMON.
CM1-SC01B, CM1-SC02A (CH2)
Make communication settings using the application software “CICON”. For more information, refer to the instruction manual
issued by CIMON.
Item Setting Remarks
Protocol CICON(Loader) Protocol
Baud Rate 9600 / 19200 / 38400 bps
Parity Even / Odd / None
Data Bit 7 / 8 bits
Stop Bit 1 / 2 bits
Item Setting Remarks
Comm Type RS422 / RS485
RS-422: 4-wire
RS-485: 2-wire
Protocol CICON(Loader) Protocol
Baud Rate 9600 / 19200 / 38400 bps
Parity Even / Odd / None
Data Bit 7 / 8 bits
Stop Bit 1 / 2 bits
To Next Page
