10.1 Temperature Controller/Servo/Inverter Connection 10-1
10.1 Temperature Controller/Servo/Inverter Connection
Serial Connection
Motion Controller
Ethernet Connection
Motion Controller
*1 For KeepAlive functions, see “1.3.2 Ethernet Communication”.
PLC Selection
on the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
PMAC
PMAC PCI Serial port J4
RS-232C
Wiring diagram 1 - C2 Wiring diagram 1 - M2
PMAC.Lst
Turbo PMAC PCI Option-9T J8
Wiring diagram 2 - C2 Wiring diagram 2 - M2
PMAC2 PCI Serial port J5
Turbo PMAC2 PCI Option-9T J8
UMAC Turbo CPU
Serial port J7
Sub-serial port J8
3U Turbo PMAC2
Serial port J7 Wiring diagram 1 - C2 Wiring diagram 1 - M2
Option-9T J8 Wiring diagram 2 - C2 Wiring diagram 2 - M2
PLC Selection on the
Editor
Model Unit TCP/IP UDP/IP Port No.
Keep
Alive
*1
Lst File
PMAC
(Ethernet TCP/IP)
UMAC Turbo CPU
CPU with built-in
Ethernet
1025
(max. 4 units)
PMAC_Eth.Lst
