10.1.1 PMAC
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PMAC
Make PMAC settings by using the software “PEWIN32PRO2”. For more information, refer to the PMAC instruction manual
issued by the manufacturer.
Values after change are saved in FROM and determined when the power is turned off and back on again.
I-Variables by number
*1 Set when Turbo PMAC PCI, Turbo PMAC2 CPCI, UMAC Turbo CPU or 3U Turbo PMAC2 is used.
*2 Valid when “Option-9T” is used with Turbo PMAC PCI, Turbo PMAC2 CPCI / 3U Turbo PMAC2 or the sub port of UMAC Turbo CPU is used.
*3 When “115K bps” is set, set the multiples of 30 MHz for “I52” (CPU frequency).
PMAC PCI
MAIN BOARD E-POINT
Item Setting Remarks
Connection Mode 1 : 1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C
Baud Rate
4800 / 9600 / 19200 / 38400
/ 57600 / 76800 /
115K bps
Data Length 8 bits
Stop Bit 1 bit
Parity None
Targe t Por t N o. 0
to 31
Address Contents Setting
I0 Serial card number 0: 1:1 connection
I1 Serial port mode 0: CTS signal used
I3 Handshake I/O control 2
I4 Communication sum check mode 0: Without sum check
I6 Error notification mode 1
I43
Protocol selection
*1
0: Standard protocol
I53
Sub port
*2
Baud rate
6: 4800, 8: 9600, 10: 19200, 12: 38400, 13: 57600, 14: 78600,
15: 115K
*3
bps
I54 Main port
Baud rate
6: 4800, 8: 9600, 10: 19200, 12: 38400, 13: 57600, 14: 78600,
15: 115K
*3
bps
I63 Echo back selection 1: Valid
E-POINT Contents Setting
E49 Parity control for serial communication No parity: Install a jumper between pins 1 and 2.
E110 Serial port setting RS-232C: Install a jumper between pins 1 and 2.
