10-8 10. DELTA TAU DATA SYSTEMS
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
* In the expansion code, set which word, higher or lower, is to be read when a double-word address is specified
(expansion bit designation).
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
* Depends on the time set for [Time-out Time] under [Communication Setting] in the [PLC Properties] window ([System Setting] 
[Hardware Setting]).
Device Memory TYPE Remarks
P (variable P) 00H Real number
Q (variable Q) 01H Real number
M (variable M) 02H Real number
I (variable I) 03H Real number
M_INT (variable M (integer)) 04H Double-word
I_INT (variable I (integer)) 05H Double-word
P_INT (variable P (integer)) 06H Double-word
15 8 7 0
n + 0 Model Device type
n + 1 Address No.
n + 2
Expansion code
*
Bit designation
n + 3 00 Station number
15 8
0000000
Expansion bit designation
0: 0 to 15 bits
1: 16 to 31 bits
Contents F0 F1 (= $u n) F2
Write of data
1 - 8
(PLC1 - 8)
nStation number
3
n + 1 Command: 0000H
n + 2
Timeout time: 1 to 300 sec.
(0: Time set on the editor*)
Control-X
1 - 8
(PLC1 - 8)
nStation number
2
n + 1 Command: 0001H
