16-22 16. Fuji Electric
Inverter
IH Inverter
AC Power Monitor
*1 Select a model on which RS-485 or RS-232C communication is available.
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
FVR-E11S
FVRxxE11S-x
Touch panel
connector
RS-485 Wiring diagram 6 - C4 Wiring diagram 6 - M4
FVR-E11S.Lst
FVR-E11S
(MODBUS RTU)
FVR-E11S
(Modbus).Lst
FVR-C11S
(MODBUS RTU)
FVRxxC11S-x
OPC-C11S-RSx RS-485 Wiring diagram 7 - C4 Wiring diagram 7 - M4
FVR-C11S
(Modbus).Lst
FRENIC5000G11S /
P11S
FRNxxG11S-x
FRNxxP11S-x
Terminal block RS-485 Wiring diagram 8 - C4 Wiring diagram 8 - M4
F-G11S.Lst
FRENIC5000G11S /
P11S (MODBUS RTU)
FRENIC5000G1
1S_P11S
(Modbus).Lst
FRENIC5000VG7
(MODBUS RTU)
FRNxxVG7S-x
RS-485
connector
RS-485
Wiring diagram 9 - C4 Wiring diagram 9 - M4
FRENIC5000VG
7S
(Modbus).Lst
OPC-VG7-RS
(communication
board)
Wiring diagram 8 - C4 Wiring diagram 8 - M4
FRENIC-Mini
(MODBUS RTU)
FRNxxC1S-x
OPC-C1-RS
(communication
board)
RS-485 Wiring diagram 10 - C4 Wiring diagram 10 - M4 F-Mini.Lst
FRENIC-Eco
(MODBUS RTU)
FRNxxF1S-x
Touch panel
connector
RS-485
Wiring diagram 10 - C4 Wiring diagram 10 - M4
F-Eco
(Modbus).Lst
OPC-F1-RS
(communication
board)
Wiring diagram 8 - C4 Wiring diagram 8 - M4
FRENIC-Multi
(MODBUS RTU)
FRNxxE1S-x
Touch panel
connector
RS-485
Wiring diagram 10 - C4 Wiring diagram 10 - M4
F-Multi.Lst
OPC-E1-RS
(communication
board)
Wiring diagram 10 - C4 Wiring diagram 10 - M4
FRENIC-MEGA
(MODBUS RTU)
FRNxxxG1x-xx
Touch panel
connector
RS-485
Wiring diagram 10 - C4 Wiring diagram 10 - M4
FRENIC-
MEGA
(Modbus).Lst
Terminal block on
control circuit
Wiring diagram 8 - C4 Wiring diagram 8 - M4
FRENIC-MEGA SERVO
(MODBUS RTU)
FRNxxxG1x-xxxQ
Touch panel
connector
RS-485
Wiring diagram 10 - C4 Wiring diagram 10 - M4
FRENIC-
MEGA SERVO
(Modbus).Lst
Control circuit
terminal block
Wiring diagram 8 - C4 Wiring diagram 8 - M4
FRENIC-HVAC/AQUA
(MODBUS RTU)
FRNxxxAR1x-4x
FRNxxxAQ1x-4x
Touch panel
connector
RS-485
Wiring diagram 10 - C4 Wiring diagram 10 - M4
FRENIC-HVAC
(Modbus).Lst
FRENIC-AQUA
(Modbus).Lst
Control circuit
terminal block
Wiring diagram 8 - C4 Wiring diagram 8 - M4
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
HFR-C9K
HFR030C9Kxx
HFR050C9Kxx
HFR-OPC01
(communication
board)
RS-485 Wiring diagram 13 - C4 Wiring diagram 13 - M4 F_HFR.Lst
HFR-C11K
HFR3.0C11Kxx
HFR5.0C11Kxx
HFR7.0C11Kxx
Terminal block RS-485 Wiring diagram 8 - C4 Wiring diagram 8 - M4 HFR-C11K.Lst
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
PPMC
(MODBUS RTU)
PPMCxx
*1
Term inal bloc k
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
F-PPMC.Lst
RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4
