16.2 Temperature Controller/Servo/Inverter Connection 16-23
Servo Amplifier
*1 Select a model on which host interface: universal communication (RS-485) is available.
Controller
Recorder
Digital Panel Meter
*1 Specify an input unit (-yy: 01 to 12, or 18) when selecting the model.
AC Power Regulator
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
FALDIC- series RYSxx
*1
CN3 RS-485 Wiring diagram 12 - C4 Wiring diagram 12 - M4 F_FAL-A.Lst
FALDIC-W series
RYCxxx
x3-VVT2
CN3A (UP port) RS-485 Wiring diagram 17 - C4 Wiring diagram 17 - M4 F_Fal-W.Lst
ALPHA5
(MODBUS RTU)
RYTxxxx5-VV
x
CN3A RS-485 Wiring diagram 14 - C4 Wiring diagram 14 - M4 ALPHA5.Lst
ALPHA5 Smart
(MODBUS RTU)
RYHxxxF5-V
V2
CN3A RS-485 Wiring diagram 14 - C4 Wiring diagram 14 - M4
ALPHA5Smart.L
st
PLC Selection on the
Editor
Model Port
Signal
Level
Connection
Lst File
CN1 MJ1/MJ2
WSZ series
WSZ-24MCT2-AC
WSZ-32MCT2-AC
WSZ-40MCT2-AC
WSZ-60MCT2-AC
PORT0 RS-232C Wiring diagram 3 - C2 Wiring diagram 3 - M2
WSZ.Lst
WSZ-CB25
PORT1 RS-232C Wiring diagram 4 - C2 Wiring diagram 4 - M2
PORT2 RS-485 Wiring diagram 18 - C4 Wiring diagram 18 - M4
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
PH series
PHAxxxx4-xxxRY
PHCxxxx3-xxxRY
Terminal block RS-485 Wiring diagram 16 - C4 Wiring diagram 16 - M4 F_PHC.Lst
PHR (MODBUS RTU) PHRxx Terminal block RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4 F_PHR.Lst
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
WA5000
WA5xx3-yy
WA5xx4-yy
WA5xx6-yy
WA5xx7-yy
*1
Modular Jack
RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
WA5000.Lst
RS-485 Wiring diagram 11 - C4 Wiring diagram 11 - M4
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
APR-N
(MODBUS RTU)
RPNExxxx-xx-ZA
M-xx/xx
RPN003-AM
(communication
board)
RS-485 Wiring diagram 4 - C4 Wiring diagram 4 - M4 F_APR-N.Lst
