*1 List files “F_WE1MA.Lst” and “F_WE1MA(Ver. B).Lst” can be browsed as default through the [Refer] button. These files can be used for
device memory settings.
PLC Selection on
the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
WE1MA (Ver. A)
(MODBUS RTU)
WE1MA-AFxxx-Mxx
Terminal block RS-485 Wiring diagram 15 - C4 Wiring diagram 15 - M4
F_WE1MA.Lst
WE1MA-AGxxx-Mxx
WE1MA-A1xxx-Mxx
F_WE1MA_1P.Lst
*1
WE1MA-A5xxx-Mxx
WE1MA-A2xxx-Mxx
F_WE1MA_1P3L.L
st
*1
WE1MA-A6xxx-Mxx
WE1MA-A3xxx-Mxx
F_WE1MA_3P3L.L
st
*1
WE1MA-A7xxx-Mxx
WE1MA-A4xxx-Mxx
F_WE1MA_3P4L.L
st
*1
WE1MA (Ver. B)
(MODBUS RTU)
WE1MA-AFxxx-Mxx
Terminal block RS-485 Wiring diagram 15 - C4 Wiring diagram 15 - M4
F_WE1MA
(Ver. B).Lst
WE1MA-AGxxx-Mxx
WE1MA-A1xxx-Mxx
F_WE1MA_1P
(Ver. B).Lst
*1
WE1MA-A5xxx-Mxx
WE1MA-A2xxx-Mxx
F_WE1MA_1P3L
(Ver. B).Lst
*1
WE1MA-A6xxx-Mxx
WE1MA-A3xxx-Mxx
F_WE1MA_3P3L
(Ver. B).Lst
*1
WE1MA-A7xxx-Mxx
WE1MA-A4xxx-Mxx
F_WE1MA_3P4L
(Ver. B).Lst
*1
