Hakko Electronics Monitouch V9 Series - 16.2.20 HFR-C9 K

16-64 16. Fuji Electric
16.2.20HFR-C9K
Communication Setting
Editor
Communication setting
(Underlined setting: default)
IH Inverter
Be sure to match the settings to those made under [Communication Setting] of the editor.
SW1 setting (Station address / Optional selection)
*1 For connection to a V9, be sure to set the station address other than 0.
Communication setting
Set communication parameters.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600
/ 19200 bps
Data Length 7 / 8
bits
Stop Bit 1 / 2
bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Switch Contents
Example:
Station Address: 1
Optional Selection: Selection for Communication
Operation
(Start from LSB)
1
Station
Address
*1
2
3
4
5
6
Optional
Selection
Function Code Item Setting Example
F16 Baud rate
4: 4800 bps
5: 9600 bps
6: 19200 bps
5
F17 Data length
0: 7 bit
1: 8 bits
1
F18 Parity bit
0: None
1: Even
2: Odd
1
F19 Stop bit
0: 1 bit
1: 2 bits
1
1 2 3 4 5
0 OFF OFF OFF OFF OFF
1 ON OFF OFF OFF OFF
2 OFF ON OFF OFF OFF
3 ON ON OFF OFF OFF
: :::::
28 OFF OFF ON ON ON
29 ON OFF ON ON ON
30 OFFONONONON
31 ON ON ON ON ON
Address
Switch
ON
OFF(0)
1
2
4
8
16
LSB MSB
ON(1)
123456
Contents LSB MSB
Selection for Communication Operation
(Start from LSB)
ON
OFF
Selection for Communication Operation
(Start from MSB)
OFF ON
