16.2 Temperature Controller/Servo/Inverter Connection 16-67
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
PLC_CTL
Device Memory TYPE Remarks
S(command data) 00H
M(monitor data) 01H
F (basic function) 02H
E (error display function) 03H
C (control function) 04H
P (optional function) 05H
H (high level function) 06H
o (output terminal function) 08H
i (input terminal function) 0BH
t
(control function in the event of trip
(alarm) occurrence)
0CH
r (RS communication function) 0DH
Pn (touch panel function) 0EH
Content F0 F1 (=$u n) F2
Reset command
1 - 8
(PLC1 - 8)
nStation number
2
n + 1 Command: 0
