Hakko Electronics Monitouch V9 Series - Page 330

16.2 Temperature Controller/Servo/Inverter Connection 16-77
PLC_CTL
Contents F0 F1 (=$u n) F2
Hold remote control response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 0
n + 2
Hold status
0: OFF, 1: ON
Hold terminal response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 1
n + 2
Hold status
0: OFF, 1: ON
Hold remote control
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 2
n + 2
Hold status
0: OFF, 1: ON
Trigger input
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 3
n + 2
Display type
0: Normal display
1: Over display
2: Peak hold display
3: Valley hold display
4: Peak valley hold display
n + 3 Measurement value
n + 4
Comparison result
0: OFF
1: HI
2: GO
3: LO
Hold remote control cancel
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 4
Peak hold remote control
response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 5
n + 2
Peak hold type
0: Peak hold
1: Valley hold
2: Peak valley hold
n + 3
Peak hold status
0: OFF, 1: ON
Peak hold terminal response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 6
n + 2
Peak hold status
0: OFF, 1: ON
Peak hold type setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 7
n + 2
Peak hold type
0: Peak hold
1: Valley hold
2: Peak valley hold
Peak hold remote control
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 8
n + 2
Peak hold remote
0: OFF, 1: ON
Peak hold value response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 9
n + 2 Peak hold value
n + 3 Valley hold value
n + 4 Peak valley hold value
Peak hold value clear
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 10
n + 2
Peak hold type
0: Peak hold
1: Valley hold
2: Peak valley hold
Peal hold remote control cancel
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 11
Digital zero remote control
response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 12
n + 2
Digital zero
0: OFF, 1: ON
n + 3 Displayed value
