16-78 16. Fuji Electric
Digital zero terminal response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 13
n + 2
Digital zero
0: OFF, 1: ON
Digital zero remote control
1 - 8
(PLC1 - 8)
n Station number
4
n + 1 Command: 14
n + 2
Digital zero
0: OFF, 1: ON, 2: ON when the value reaches the set
value
n + 3 Setting value
Digital zero remote control cancel
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 15
Comparison output remote
control response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 16
n + 2
Status
0: OFF
1: Set (ON) HI
2: Set (ON) GO
3: Set (ON) LO
Comparison output remote
control
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 17
n + 2
Status
0: OFF
1: Set (ON) HI
2: Set (ON) GO
3: Set (ON) LO
Comparison output remote
control cancel
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 18
Remote control response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 19
n + 2
Remote control status
Maximum / minimum / (maximum
- minimum) response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 20
n + 2 Maximum
n + 3 Minimum
n + 4 (Maximum - minimum)
Maximum / minimum / (maximum
- minimum) clear
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 21
n + 2
Maximum /minimum /(maximum - minimum) clear
0: Maximum
1: Minimum
2: Maximum - minimum
Range response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 22
n + 2
Range
0: No designation 12: J
1: Range 11 13: T
2: Range 12 14: R
3: Range 13 15: S
4: Range 14 16: B
5: Range 15 17: PA
6: Range 23 18: Pb
7: Range 24 19: JPA
8: Range 25 20: JPb
9: Range 26 21: 1V
10: KA 22: 2A
11: KB
Contents F0 F1 (=$u n) F2
Hold function
Peak hold
Digital zero
Comparison output
* No remote control is performed when all
bits are reset (OFF).
Bit - 3210
