16.2 Temperature Controller/Servo/Inverter Connection 16-79
Range setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 23
n + 2
Range
1: Range 11 12: J
2: Range 12 13: T
3: Range 13 14: R
4: Range 14 15: S
5: Range 15 16: B
6: Range 23 17: PA
7: Range 24 18: Pb
8: Range 25 19: JPA
9: Range 26 20: JPb
10: KA 21: 1V
11: KB 22: 2A
Average number of responses
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 24
n + 2
Average number of times
1 / 2 / 4 / 8 / 10 / 20 / 40 / 80 (times)
Setting for average number of
times
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 25
n + 2
Average number of times
1 / 2 / 4 / 8 / 10 / 20 / 40 / 80 (times)
Average number of movement
times
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 26
n + 2
Average number of movement times
0 (OFF) / 2 / 4 / 8 / 16 / 32 (times)
Setting for average number of
movement times
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 27
n + 2
Average number of movement times
0 (OFF) / 2 / 4 / 8 / 16 / 32 (times)
Step-wide response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 28
n + 2
Step wide
1:1, 2:2, 5:5, 0:10 (digit)
Step-wide setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 29
n + 2
Step wide
1:1, 2:2, 5:5, 0:10 (digit)
Communication function
parameter response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 30
n + 2
Baud rate
0: 2400, 1: 4800, 2: 9600,
3: 19200, 4: 38400
n + 3
Data length
0: 7 bits, 1: 8 bits
n + 4
Parity
0: none, 1: odd, 2: even
n + 5
Stop bit
0: 1 bit, 1: 2 bits
n + 6
Delimiter
0: CR/LF, 1: CR
Communication function
parameter setting
1 - 8
(PLC1 - 8)
n Station number
7
n + 1 Command: 31
n + 2
Baud rate
0: 2400, 1: 4800, 2: 9600,
3: 19200, 4: 38400
n + 3
Data length
0: 7 bits, 1: 8 bits
n + 4
Parity
0: none, 1: odd, 2: even
n + 5
Stop bit
0: 1 bit, 1: 2 bits
n + 6
Delimiter
0: CR/LF, 1: CR
Unit ID response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 32
n + 2
Unit ID
1 to 99
Unit ID setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 33
n + 2
Unit ID
1 to 99
Contents F0 F1 (=$u n) F2
