16-80 16. Fuji Electric
Analog output type response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 34
n + 2
Analog output type
0: Not provided
1: OFF
2: 0 - 1 (V)
3: 0 - 10 (V)
4: 1 - 5 (V)
5: 0 - 20 (mA)
6: 4 - 20 (mA)
Analog output type setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 35
n + 2
Analog output type
1: OFF
2: 0 - 1 (V)
3: 0 - 10 (V)
4: 1 - 5 (V)
5: 0 - 20 (mA)
6: 4 - 20 (mA)
Digital zero backup status
response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 36
n + 2
Digital zero backup status
0: OFF
1: ON
Digital zero backup control
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 37
n + 2
Digital zero backup status
0: OFF
1: ON
Digital zero data save command
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 38
Input change response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 39
n + 2
Input change
0: Not provided
1: Open collector
2: Logic
3: Magnetic
Input change setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 40
n + 2
Input change
1: Open collector
2: Logic
3: Magnetic
Tracking zero response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 41
n + 2
Tracking zero time
0 (OFF) / 1 to 99
n + 3
Tracking zero width
0 (OFF) / 1 to 99
Tracking zero time setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 42
n + 2
Tracking zero time
0 (OFF) / 1 to 99
Tracking zero width setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 43
n + 2
Tracking zero width
0 (OFF) /1 to 99
Sensor power response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 44
n + 2
Sensor power
0: 5 V
1: 10 V
Sensor power setting
1 - 8
(PLC1 - 8)
n Station number
3
n + 1 Command: 45
n + 2
Sensor power
0: 5 V
1: 10 V
Power-on delay time response
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 46
n + 2
Power-on delay time
0 (OFF) / 1 to 30
Contents F0 F1 (=$u n) F2
