Hakko Electronics Monitouch V9 Series - 17.1.2 Wiring Diagrams

17.1 Temperature Controller / Servo / Inverter 17-5
17.1.2 Wiring Diagrams
When Connected at CN1:
RS-422/RS-485
Wiring diagram1 - C4
When Connected at MJ1/MJ2:
RS-422/RS-485
Wiring diagram 1 - M4
No.Name
Dsub 9 (Male)
2
3
5
7
8
+RD
-RD
-SD
+SD
SG
FG
CN1
PLC
2
No.
3
4
5
Name
Dsub 9 (Male)
5
9
1
6
5
9
1
6
+RD/+SD
-RD/-SD
SG
* Use shielded twist-pair cables.
No.
RJ-45
1
2
5
+RD/+SD
-RD/-SD
SG
FG
MJ1/2
Name
12345678
PLC
2
No.
3
4
5
Name
Dsub 9 (Male)
5
9
1
6
+RD/+SD
-RD/-SD
SG
* Use shielded twist-pair cables.
