Hakko Electronics Monitouch V9 Series - Page 362

17-4 17. Gammaflux
Turn All Zones On/Off
1 - 8
(PLC1 - 8)
nStation number
7
n + 1 ZONE No.: Fixed to 0
n + 2
ZONE COMMAND
0099H (Storage device memory: Volatile)
8099H (Storage device memory: Nonvolatile)
n + 3
n + 4
n + 5
n + 6
Zones Temporarily in
Group
1 - 8
(PLC1 - 8)
nStation number
7
n + 1 ZONE No.: Fixed to 0
n + 2
ZONE COMMAND
009AH (Storage device memory: Volatile)
809AH (Storage device memory: Nonvolatile)
n + 3
n + 4
n + 5
n + 6
Contents F0
F1 (=$u n)
F2
Bit
15 14 - 2 1 0
Zone1
Zone16
Bit
15 14 - 2 1 0
Zone17
Zone32
Bit
15 14 - 2 1 0
Zone33
Zone48
Bit
15 14 - 2 1 0
Zone49
Zone64
Bit
15 14 - 2 1 0
Zone1
Zone16
Bit
15 14 - 2 1 0
Zone17
Zone32
Bit
15 14 - 2 1 0
Zone33
Zone48
Bit
15 14 - 2 1 0
Zone49
Zone64
