Hakko Electronics Monitouch V9 Series User Manual

2.1 PLC Connection 2-3
SW-6 (RS-232C communication rate and diagnostic commands)
Series B 1785-KE
SW-1 (RS-232C link features)
SW-2 (node number)
SW-3 (communication rates and local/remote option)
SW-4 (for future use)
* Series B 1785-KE switch: ON = 0: DOWN (lower), OFF = 1: UP (upper)
No. Item Setting Remarks
1
RS-232C Communication Rate
Set the same value as the one set
on V9.
2
3
4 Diagnostic Commands ON Execute diagnostic commands
No. Item Setting Remarks
1-3 RS-232C Link Features
SW1: OFF
SW2: OFF
SW3: OFF
Error check: BCC
Parity: None
Embedded response: No
SW1: ON
SW2: OFF
SW3: OFF
Error check: BCC
Parity: Even
Embedded response: No
4 Detect duplicate messages ON
Detect and ignore duplicate
messages
5 Hand shaking signals OFF Ignore handshaking signals
6 Diagnostic Commands ON Execute diagnostic commands
No. Item Setting Remarks
1
Octal Digit 0 0
SW1: ON
SW2: ON
2
3-5 Octal Digit 1
Setting example:
Station number 15 (DEC) = 17
(OCT)
SW3-5: ON, OFF, OFF
SW6-8: ON, ON, ON
6-8 Octal Digit 2
No. Item Setting Remarks
1
Network Communication Rate
ON
57600 bps For DH+ port
2 ON
3-5 RS-232 Link Baud Rate
Set the same value as the one
set on V9.
6 Local / Remote operation ON Local mode
No. Setting Remarks
1-4 OFF Always OFF (system reserved)
4800 bps 9600 bps 19200 bps
SW1 ON OFF ON
SW2 OFF ON ON
SW3 ON ON ON
No. 0 1 2 3 4 5 6 7
SW3 OFF ON OFF ON OFF ON OFF ON
SW4 OFF OFF ON ON OFF OFF ON ON
SW5OFFOFFOFFOFFONONONON
No. 0 1 2 3 4 5 6 7
SW6 OFF ON OFF ON OFF ON OFF ON
SW7 OFF OFF ON ON OFF OFF ON ON
SW8OFFOFFOFFOFFONONONON
4800 bps 9600 bps 19200 bps
SW3 ON OFF ON
SW4 OFF ON ON
SW5ONONON
