9-9
MAINTENANCE, PERIPHERALS
9.3.1 Connecting an External Display
The information shown on the titrator display can be viewed also on a Standard VGA display
connected with a 15-pin cable, as presented below.
Connect the external display to the display socket.
Turn on the titrator and then the external display.
9.3.2 Connecting an External PC Keyboard
This connection allows you to use an external PS/2 PC Keyboard in addition to the titrator’s
keypad.
Connect an external PC Keyboard (PS/2 connector).
