Hanna Instruments HI 902 Color - Attaching the Burette

2-9
SETUP
2.3.4.5 Attaching Burette
Make sure that the mark from the valve actuating cap and from the burette body are aligned
as shown in Figure 2.
While ensuring the correct coupling between the syringe plunge (1) and the pump piston (2)
(Figure 3), slide the burette into the support on the burette pump (Figure 4).
Figure 2
Figure 3 Figure 4
