Hanna Instruments HI 902 Color - Titrator Assembly; Assembling Stirrer Stand and Support; Titrator Left-Side View

2-6
SETUP
2.3.3 Titrator Left-side View
2.3.4 Titrator Assembly
Note: Assembly operations must be completed before connecting the titrator to the power supply!
2.3.4.1 Assembling Stirrer Stand and Support
To assemble the stirrer stand and support:
• Remove the screws (B) from the titrator base (A).
• Attach the stirrer stand (C) to the titrator.
• Tighten the stirrer stand (C) using the previously removed screws (B).
• Screw the stirrer support (D) in the stirrer stand (C).
