3-5
USER INTERFACE
3.2.1.3 Arrow Keys
These keys have the following functions:
• Move the on-screen cursor.
• Increase and decrease the stirrer speed and other settings.
• In the alphanumeric screen, to select a character.
• Navigate through menu options.
3.2.1.4 Numeric Keys
Keys to Used for numeric entries.
Toggles between positive and negative values.
Decimal point.
Initiates entry of exponent for scientific notation.
3.2.1.5 Enter Key
Both , keys perform the same functions:
• Accept alphanumeric data entry.
• Executes the default (underlined) virtual option key.
3.2.2 Display
The titrator has a large color graphical display.
The main screen
is shown below with short
explanations of the screen segments.
