HERMA 400 APPLICATOR DESCRIPTION
3.28 US (130519) 33/154
> Remove disk 10 (fig. F). The motor is now held only by plug 11 (fig. G). Loosen the plug and remove
the motor.
> The circuit board can be removed carefully. To do so first lift it at the side opposite to button 12 
(fig. H).
> If you need to replace board 13 (fig. I) make sure to take note of the correct direction when
inserting the new board (do not turn by 180°).
H
12
I
13
