6
Transport, installation, storage and connection Operating instructions HERMA 400
80/154 3.28 US (130519)
Only use the machine in dry areas.
Mount the applicator appropriately before supplying energy.
If persons that were not properly instructed for using the applicator
various risks may occur. Installation/removal shall only be performed by
trained specialists when the applicator is disconnected from the mains
supply. Mount the applicator appropriately before supplying energy and
put any protective covers back on.
Mount the applicator using the two mounting holes for round rods (2), Ø 30 mm, hole spacing: 182 mm.
Secure the mounting system appropriately on the rods, e.g. using a locking screw (3), a wash
er (4) or
the optional fine-adjustment device (5).
For information on fixing the applicator to various take-up systems see the following illustrations and
information:
