Hirschmann HiSecOS EAGLE30 - Port

Diagnostics > Status Configuration > Security Status
Diagnostics
432
RM GUI HiSecOS EAGLE20/30
Release 3.0 09/2015
9.3.2 Port
 Table
 Buttons
Parameters Meaning
Link interrupted on
enabled device
ports
Activates/deactivates the monitoring of the link on the active ports.
Possible values:
 marked
Monitoring is active.
The "Security Status" changes to "Error" when the port is enabled
(
Basic Settings > Port dialog, "Configuration" tab, "Port on"
checkbox is
marked ) and the link is down on the port.
 unmarked (default setting)
Monitoring is inactive.
This setting takes effect when you mark the "Link interrupted on enabled
device ports" checkbox in the
Diagnostics > Status Configuration >
Security Status dialog, "Global" tab.
Button Meaning
Set Transfers the changes to the volatile memory (
RAM ) of the device and
applies them to the device. To save the changes in the non-volatile
memory, proceed as follows:
 Open the
Basic Settings > Load/Save dialog.
 In the table, highlight the desired configuration profile.
 If in the "Selected" column the checkbox is
unmarked , click the
"Select" button.
 Click the "Save" button.
Reload Updates the fields with the values that are saved in the volatile memory
(
RAM ) of the device.
Help Opens the online help.
