4. Close the top cover of server blade. See Closing a top cover, Server blade
on page 5-39 section.
5. Close the top cover of PCI expansion blade. See Closing a top cover, PCI
expansion blade on page 5-41 section.
6. Install the PCI expansion blade. See Installing a PCI expansion blade into
server chassis on page 5-16 section.
Replacing a lithium battery in half-wide server blade
This procedure describes how to remove a lithium battery from the server
blade.
Removing a lithium battery
1. Put on an anti-static wrist strap.
2. Remove the target server blade.
See
Removing a half-wide server blade on page 5-4 section.
3. Open the top cover of the server blade. See Opening a top cover, Server
blade on page 5-38 section.
4. Tilt the lithium battery in the direction shown by the arrow, and then lift it
away from the battery holder.
Figure 5-103 Removing the lithium battery- CB 520A A1
