No. Name State Description
8 Buzzer stop
switch
(BZSTP)
- Stops the buzzer
Server blade
Figure 1-35 Half-wide Server blade (CB 520A A1, CB 520H A1/B1/B2)
Figure 1-36 Half-wide Server blade (CB 520H B3/B4)
Figure 1-37 Full-wide Server blade (CB 540A A1/B1)
1-26
Introduction
Hitachi Compute Blade 500 Series System Service Manual
