Figure 1-13 Disk drive location
Table 1-9 Location of installable components
Symbol Component
0 HDD #0
2 HDD #2
Disk drive numbering: Storage expansion blade
The disk drive numbering in a storage expansion blade is #0 to #6 from the
bottom to top, as viewed from the front of the storage expansion blade.
Numbering applies to all blades in the server chassis.
Figure 1-14 Disk drive location
Table 1-10 Location of installable components
Symbol Component Symbol Component
0 HDD #0 4 HDD #4
1 HDD #1 5 HDD #5
2 HDD #2 6 HDD #6
1-10
Introduction
Hitachi Compute Blade 500 Series System Service Manual
