17. Enter y , and then press Enter key.
18. The following message is displayed. Confirm "Update is finished
successfully." message.
Note: Do not power off the switch module and disconnect the LAN cable
during updating the firmware.
8Gb / 16Gb FC switch module
1. Click Start > Programs > Accessories > Communications >
HyperTerminal to boot up terminal software.
2. The Connection Description window is displayed. Enter telnet1, and
then click OK.
3. Select TCP/IP (Winsock), enter < IP address > in the Host address,
and then click OK.
< IP address >:IP address for the target switch module. See Internal IP
address setup procedure for switch module on page 4-18 section.
4. The login prompt is displayed in the terminal.
9-8
Updating firmware
Hitachi Compute Blade 500 Series System Service Manual
