DIMM numbering: CB 520X B1/B2/B3
The DIMM numbering in CB 520X B1/B2/B3 is #1 to #48 shown as following
figure.
Figure 1-22 DIMM in CB 520X B1/B2/B3
Table 1-18 Location of DIMMs in CB 520X B1/B2/B3
Symbol Component Symbol Component Symbol Component Symbol Component
1 DIMM #1 13 DIMM #13 25 DIMM #25 37 DIMM #37
2 DIMM #2 14 DIMM #14 26 DIMM #26 38 DIMM #38
3 DIMM #3 15 DIMM #15 27 DIMM #27 39 DIMM #39
4 DIMM #4 16 DIMM #16 28 DIMM #28 40 DIMM #40
5 DIMM #5 17 DIMM #17 29 DIMM #29 41 DIMM #41
6 DIMM #6 18 DIMM #18 30 DIMM #30 42 DIMM #42
7 DIMM #7 19 DIMM #19 31 DIMM #31 43 DIMM #43
8 DIMM #8 20 DIMM #20 32 DIMM #32 44 DIMM #44
9 DIMM #9 21 DIMM #21 33 DIMM #33 45 DIMM #45
10 DIMM #10 22 DIMM #22 34 DIMM #34 46 DIMM #46
1-16
Introduction
Hitachi Compute Blade 500 Series System Service Manual
