Setting Temperature
1
Select the target group for the change of setting temperature at the “Monitor 1 (All Groups)” or “Monitor 2 (Block)”
screens. The screen with the settings for the selected group is displayed on the touchscreen.
Monitor 1 (All Groups) Monitor 2 (Block)
(1)
(1)
2 By tapping “ ”, the temperature is increased by 1 ºC. (Max. 30 ºC). By tapping “ ”, the temperature is decreased by
1 oC. (Min. 9 ºC in cooling, dry and fan operation; Min. 17 ºC in heating operation)
3 Tap “Monitor screen” to return to the “Monitor” screen.
(2)(3)
NOTE
• When there are two or more groups registered in the same block, it is possible to change the target group for setting by tapping the
arrow buttons at the upper corners of the screen.
• In case that control mode is set as “Run/Stop Only”, setting changes affect all groups or all blocks.
It is not possible to change settings for each group.
• The gure above shows an example of a connected air conditioner unit. The setting temperature may not be indicated in certain
cases.
5 Centralised remote controls
PSC-A32MN
TCGB0106 rev.0 - 12/2014
324
