6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
439439
6
Network settings
CAUTION
• If this is the rst time that CSNET WEB is being run in this installation, we recommend using the CD supplied with the interface, as
explained in section Conguring the hardware.
• The network settings specify the parameters for conguring CSNET WEB to be able to communicate with the rest of the network.
These parameters are essential, and a bad conguration may cause conicts in the local area network. This is why we recommend
that for making these settings you get in touch with the network administrator where CSNET WEB will be installed.
To enter and/or modify the network conguration click on Change button in Network settings section and follow these
steps:
1 Enter the IP address. The IP address consists of four numbers which must be between 0 and 255.
2 Enter the Mask. As in the case of the IP address, the four numbers must be between 0 and 255.
3 Enter the IP address of the Gateway. Again, the numbers for these four elds follow the same rule as the IP address and
Mask. If you do not have a Gateway, the eld should contain an IP address within the margins of the specied network.
4 Click on the OK button situated in the upper right (by the IP line). A message will appear as in the example:
OK
5 When you press the OK button, changed CSNET WEB will restart and therefore communication with it will be lost by
approximately 2 minutes.
If harc is doing auto conguration, it will not be able to modify settings from that pane. User must wait for the end of auto
conguration.
Version and updates
Version and updates gives the information to the user about which software is installed on the HARC.
If the internet connection is properly congured, it can download updates for the HARC and install them just by clicking
the button.
CAUTION
HARC cannot be updated through a proxy.
