7 Gateways for building management systems
KNX001
TCGB0106 rev.0 - 12/2014
661661
7
3 Indicates the time in seconds that these requests will be delayed to prevent overload in the KNX bus,
due to other KNX devices behaving in the same way.
6
5
7
1
2
3
8
4
CSNET WEB settings
1 CSNET WEB IP address.
2 CSNET WEB TCP port, normally 502.
3 Timeout between data requests to CSNET WEB.
4 List of devices to use. For a device to be used in the KNX, it must be selected in the check box in the list. Each device
has the following properties:
5 System No., identiîš¿es each Hitachi refrigeration system.
6 Unit No., identiîš¿es each Hitachi unit.
7 Descriptive name of the device. An optional îš¿eld.
8 Permits selection of the number of devices to be used in the installation. On changing this parameter the conîš¿guration
window closes. When it is opened again, the number of devices selected will appear in the list. Up to 128 devices are
allowed.
