Items Optional Function
Indi-
vidual
setting
Setting
condition
Contents
F8
Lock function for
operation mode
selection
×
00 Not available
01
Available (Factory
setting)
F9
Lock function for
temperature setting
×
00 Not available
01
Available (Factory
setting)
FA
Lock function for
fan speed selection
×
00 Not available
01
Available (Factory
setting)
Fb
Lock function
for swing louver
operation
×
00 Not available
01
Available (Factory
setting)
FC
Cooling lower
limit for setting
temperature (*5)
×
00 Standard
01 Lower limit +1 ºC
02 Lower limit +2 ºC
... ...
09 Lower Limit +9 ºC
10 Lower Limit +10 ºC
Fd
Heating upper
limit for setting
temperature (*6)
×
00 Standard
01 Upper limit –1
o
C
02 Upper limit –2
o
C
... ...
11 Upper limit –11
o
C
12 Upper limit –12
o
C
FE
Not prepared -
00
01
Not used
(Use as 00 conditions)
FF
Not prepared -
00
01
Not used
(Use as 00 conditions)
H1
Not prepared -
00
01
Not used
(Use as 00 conditions)
H2
Indication of hot
start
×
00
01
Indication
No indication
H3
Not prepared -
00
01
Not used
(Use as 00 conditions)
H4
Not prepared -
00
01
Not used
(Use as 00 conditions)
J1
Temperature
indication (*8)
×
00
01
Not available
Available
J2
Not prepared - - Not Used
J3
Run indicator color ×
00
01
Green
Red
J4
Not prepared -
00
01/02
Not used
(Use as 00 conditions)
J5
Not prepared ×
00
01
Not used
(Use as 00 conditions)
J6
Error sound ×
00
01
Once
Sequence
J7
Not prepared -
00
01
Not used
(Use as 00 conditions)
Items Optional Function
Indi-
vidual
setting
Setting
condition
Contents
J8
Eco-operation (*9) ×
00
01
Not available
Available
J9
Not prepared -
00
01
Not used
(Use as 00 conditions)
JA
Not prepared -
00
01
Not used
(Use as 00 conditions)
Jb
Not prepared -
00
01
Not used
(Use as 00 conditions)
K1
Not prepared × - Not used
K2
Not prepared × - Not used
K3
Not prepared × - Not used
K4
Not prepared - 00~03 Not used
K5
Human sensor
detection level
(*11)
-
00
01
02
Standard
High
Low
(*1): The “02” setting may not be available according to the type of
indoor unit.
(*2):In case of RPI models, 00: standard, 01: high static pressure,
02: low static pressure
(*3): E1 to E4: Setting for the total heat exchanger and Econofresh.
(*4): In case that the set temperature is changed and kept within
the set time at “F4”, the temperature is automatically changed to
“F5” and “F6”. (In case that the set temperature is out of range at
“F5” and “F6”, it is applied within upper and lower limit for the set
temperature.)
(*5): Applicable to fan, cooling and dry operation modes.
(*6): Applicable to heating operation mode.
(*7): Operation is stopped by pressing the “
” (run/stop) switch for
3 seconds.
(*8): The sensor value at “C8” will be indicated. When the thermistor
for remote control switch is used, the average value of the thermis-
tor for remote control switch and the thermistor for indoor inlet will
be indicated.
(*9): When the unit is restarted by the remote control switch, the
temperature automatically changes to the setting temperature of
“F5” or “F6”.
(*10): If function F2 is set up 01 (Sub) is displayed “--”.
(*11): This function is for air panel with motion sensor. If the air
panel don’t have available the motion sensor, setting condition is
displayed as “--”.
NOTE
• After at least 3 minutes from the power ON, change the optional
setting.
• When changing “CF” setting (change of louver swing range), re-
store the power supply or allow the louver to make one complete
swing fully in the auto swing mode to apply the optional setting.
• The optional settings are different according to the indoor and
outdoor unit models. Check to ensure that the unit has the op-
tional setting or not.
• Record the setting conditions for each optional setting in the
“Setting” column of the table.
4 Individual remote controls
PC-ARF
TCGB0106 rev.0 - 12/2014
72
