Table B Input and Output Number Display and Connectors
Input number display
Port
Factory setting
Input/Output indication Setting item Indication
Input 1 CN3 1-2 Remote ON/OFF 1 (Level) 03
Input 2 CN3 2-3 Prohibiting Remote Control after Manual Stoppage 06
Output 1 CN7 1-2 Operation 01
Output 2 CN7 1-3 Alarm 02
Output 3 CN8 1-2 Thermo-ON for Heating 06
Table C Input and Output Settings and Display Codes
Indication Input Output
00 Not set Not set
01 Room Thermostat (for Cooling) Operation
02 Room Thermostat (for Heating) Alarm
03 Remote ON/OFF 1 (Level) Cooling
04 Remote ON/OFF 2 (Operation) Thermo-ON for Cooling
05 Remote ON/OFF 2 (Stoppage) Heating
06 Forbidding Remote Control after Manual Stoppage Thermo-ON for Heating
07 Remote Cooling / Heating Change Total Heat Exchanger
08 Elevating Grille Input Elevating Grille Output
NOTE
• After at least 3 minutes from the power ON, change the optional setting.
• The elevating grille input can be set to “Input 2” only.
• The elevating grille cannot be set to “Input 1”.
• The elevating grille output can be set to “Output 1” or “Output 2” only.
• The elevating grille output cannot be set to “Output 3”.
• Do not set the elevating grille for the total heat exchanger.
• Record the setting conditions for each input and output in the “Setting” column of the table.
