119
BW Unresrv[2]: 6250 Bytes/sec BW Unresrv[3]: 6250 Bytes/sec
BW Unresrv[4]: 6250 Bytes/sec BW Unresrv[5]: 6250 Bytes/sec
BW Unresrv[6]: 6250 Bytes/sec BW Unresrv[7]: 6250 Bytes/sec
Unreserved BW for Class Type 1:
BW Unresrv[0]: 0 Bytes/sec BW Unresrv[1]: 0 Bytes/sec
BW Unresrv[2]: 0 Bytes/sec BW Unresrv[3]: 0 Bytes/sec
BW Unresrv[4]: 0 Bytes/sec BW Unresrv[5]: 0 Bytes/sec
BW Unresrv[6]: 0 Bytes/sec BW Unresrv[7]: 0 Bytes/sec
TE Cost : 10
Bandwidth Constraint Model: Russian Doll
Bandwidth Constraints:
BC[0] : 6250 Bytes/sec BC[1] : 0 Bytes/sec
+NBR : 0000.0000.0004.00 COST: 10
Admin Group: 0x00000000
Interface IP Address: 30.1.1.1
Peer IP Address : 30.1.1.2
Physical BW : 12500 Bytes/sec
Reservable BW: 6250 Bytes/sec
Unreserved BW for Class Type 0:
BW Unresrv[0]: 6250 Bytes/sec BW Unresrv[1]: 6250 Bytes/sec
BW Unresrv[2]: 6250 Bytes/sec BW Unresrv[3]: 6250 Bytes/sec
BW Unresrv[4]: 6250 Bytes/sec BW Unresrv[5]: 6250 Bytes/sec
BW Unresrv[6]: 6250 Bytes/sec BW Unresrv[7]: 6250 Bytes/sec
Unreserved BW for Class Type 1:
BW Unresrv[0]: 0 Bytes/sec BW Unresrv[1]: 0 Bytes/sec
BW Unresrv[2]: 0 Bytes/sec BW Unresrv[3]: 0 Bytes/sec
BW Unresrv[4]: 0 Bytes/sec BW Unresrv[5]: 0 Bytes/sec
BW Unresrv[6]: 0 Bytes/sec BW Unresrv[7]: 0 Bytes/sec
TE Cost : 10
Table 44 Command output
Field Description
LSPID LSP ID
LSP Seq Num LSP sequence number
ATT/P/OL
Attach bit (ATT)
Partition bit (P)
Overload bit (OL)
NLPID Network protocol type
AREA ADDR IS-IS area address
INTF ADDR Interface address
+NBR Neighbor
COST Cost
Admin Group Link administrative group attribute
Physical BW Physical bandwidth

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
