HP 5800 Series User Manual

275
Field Description
Origin
Route origin codes. Valid values include:
i - IGP (learned from within the AS)
e - EGP (learned through EGP)
? - incomplete (learned in any other way)
Total number of routes from all PE Total number of VPNv4 routes from all PEs
Network Network address
NextHop Address of the next hop
In/Out Label Incoming and outgoing labels
MED Metric associated with the destination network
Total routes of vpn-instance vpn1 Total number of routes of the specified VPN instance
LocPrf Local preference
Paths
Counts of routes, including:
• available: Number of available routes
• best: Number of best routes
Label information
Route label information
• Received: Received label information
• Applied: Locally generated label information
Ext-Community Extended community attribute
AS-path
The route’s AS path attribute (AS_PATH), which
records all ASs the route has passed, and therefore
can avoid route loops
Attribute value BGP routing attribute information
localpref Local preference value
pref-val Preference value of the route
pre Protocol priority
State
Route status, which can be:
• valid—Valid route
• internal—Internal route
• external—External route
• local—Locally generated route
• synchronize—Synchronized route
• best—Best route
display bgp vpnv4 group
Description
Use the display bgp vpnv4 group command to display information about a specific BGP VPNv4 peer
group or all BGP VPNv4 peer groups.

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
