78
Field Description
Tunnel ID Index of the NHLFE tunnel
Out Interface Outgoing interface
AT Index Adjacency table index
Operation Label operation type, which can be PUSH, SWAP, or GO
LSP Type
LSP type, which can be LDP LSP, CR-LDP/RSVP LSP, BGP LSP, L3VPN LSP,
STATIC LSP, STATIC CR-LSP, L2VPN LSP, BGP IPv6 LSP, or INVALID
Tunnel State Tunneling state, Done or Waiting
FRR Flag FRR flag, True or False
FRR Tunnel State FRR tunnel state, Done or Waiting
Next Tunnel ID ID of the nested tunnel
Gr Count Number of times that GR occurs
Create Time Time when the entry was created
Last Change Time Time of the last update of the entry
display mpls nhlfe reflist
Description
Use the display mpls nhlfe reflist command to display the usage information of the NHLFE entries.
Syntax
display mpls nhlfe reflist token [ slot slot-number ] [ include text | { | { begin | exclude | include }
regular-expression } ]
View
Any view
Default level
1: Monitor level
Parameters
token: Specifies the NHLFE entry index. Its value ranges from 0 to 102,399.
include text: Displays the usage information of the NHLFE entries that contains a specified string. text is
the specified string.
slot slot-number: Displays the usage information of the NHLFE entries on a member device in the IRF
virtual device. The slot-number parameter is the member number of the device in the IRF virtual device.
The value range for the slot-number parameter depends on the number of members and numbering
conditions in the current IRF virtual device.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see the Fundamentals Configuration Guide.
• begin: Displays the first line that matches the specified regular expression and all lines that follow.
• exclude: Displays all lines that do not match the specified regular expression.
• include: Displays all lines that match the specified regular expression.
