HP 5800 Series User Manual

284
Configured: Active Hold Time: 180 sec Keepalive Time:60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv4 Unicast: advertised and received
Address family VPNv4: advertised and received
Received: Total 52 messages, Update messages 2
Sent: Total 65 messages, Update messages 5
Maximum allowed prefix number: 150000
Threshold: 75%
Minimum time between advertisement runs is 15 seconds
Optional capabilities:
ORF advertise capability based on Prefix(type 64):
Local: both
Negotiated: send
Connect-interface has been configured
Peer Preferred Value: 0
BFD: Enabled
Routing policy configured:
No routing policy is configured
Table 120 Command output
Field Description
Peer IP address of the peer
Local IP address of the local router
Type BGP type
BGP version Version of BGP that the peer runs.
remote router ID Router ID of the remote router.
BGP current state Current status of BGP.
Up for Duration since the peer is established.
BGP current event Current event of the peer.
BGP last state
State that BGP was in before transitioning to the
current status.
Port Local and remote BGP port numbers
Configured
Settings of the local timers, including the active hold
interval and keepalive interval.
Received Received active hold interval.
Negotiated Negotiated active hold interval.
Peer optional capabilities Optional capabilities of the peer.
Peer support bgp multi-protocol extended The peer supports multiprotocol extension.
Peer support bgp route refresh capability The peer supports route refresh capability.

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
