HP 5800 Series User Manual

36
BGP last state: OpenConfirm
Port: Local - 179 Remote - 1024
Configured: Active Hold Time: 180 sec Keepalive Time: 60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec Keepalive Time:60 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv6 Unicast: advertised and received
Received: Total 4 messages, Update messages 2
Sent: Total 6 messages, Update messages 3
Maximum allowed prefix number: 4294967295
Threshold: 75%
Minimum time between advertisement runs is 30 seconds
Optional capabilities:
Route refresh capability has been enabled
Peer Preferred Value: 0
Routing policy configured:
No routing policy is configured
Table 15 Command output
Field Description
BGP Peer IPv6 address of the BGP peer.
remote AS AS number of the peer.
Type BGP type.
BGP version Version of BGP that the peer runs.
remote router ID Router ID of the peer.
BGP current state Current state of the BGP session.
Up for Duration since the peer is established.
BGP current event Current event of the BGP session.
BGP last state
State that the BGP session was in before transitioning to the current
state.
Port Local and remote ports of the BGP session.
Configured
Settings of the local timers, including the active hold interval and
keepalive interval.
Received Received active hold interval.
Negotiated Negotiated active hold interval.
Peer optional capabilities Optional capabilities of the peer.
Peer support bgp multi-protocol
extended
The peer supports multiprotocol extension.

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
