Step
Points
Function Group
Menu Map
Description
Programming Codes
See Also
FREQUENCY
2
This softkey lets you define the number of step points in a stepped
frequency sweep.
The number of points in a stepped sweep can
range from 2 to 801. Step Size and Step Points are dependent
variables. If you know how many steps are desired in a given sweep,
use the softkey Step Points to set the desired value The step size
will be calculated automatically.
SCPI: SWEep[:FREQ
uency]:POINts
<num>)MAXimum]MINimum
Analyzer: NONE
Step Size, Step
Sup Menu, Sweep Mode Step
“Using Step Sweep” in Chapter 1
Step
Size
Function Group
FREQUENCY
Menu Map
2
Description
This softkey lets you specify the step size in a stepped frequency
sweep. The range of increment size is dependent on frequency
span and the number of step points desired, as given by the
formula: STEP SIZE = SPAN
+
STEP POINTS. Step Size and
Step Points are dependent variables, as shown by the formula. If
a particular step size is desired, use the Step Size
softkey to set
the desired increment. The number of step points is then calculated
automatically.
Programming Codes
SCPI: SWEep[:FREQ
uency]:STEP
<num>[freq suffix] or
MAXimumlMINimum
Analyzer: NONE
See Also
Step Points, Step
Swp
Menu, Sweep Mode Step
“Using Step Sweep” in Chapter 1
S-68 Operating and Programming Reference
