2 Yes low off usage usage 0.0 W 0.0 W Searching 0 -
#10 Yes low on usage usage 2.0 W 1.9 W Delivering 3^ 3
14 Yes low off usage usage 9.0 W 8.4 W Delivering 3^ 3
24 Yes low off usage lldp 7.3 W 6.9 W Delivering 4 2
# - Dual signature power delivery
^ - Power demoted ports
Example of show pow port
Example show command output at a port where LLDP is enabled for a Dual Signature PD.
Aruba-Stack-2930M(config)$ show pow 1/28
Status and Configuration Information for port 1/28
Power Enable : Yes PoE Port Status : Delivering
PLC Class/Type : 5/4 Priority Config : critical
DLC Class/Type : 5/4 Pre-std Detect : on
Alloc By Config : usage Configured Type :
Alloc By Actual : lldp PoE Value Config : n/a
PoE Counter Information
Over Current Cnt : 284 MPS Absent Cnt : 5
Power Denied Cnt : 0 Short Cnt : 0
LLDP Information
PSE Allocated Power Value : 0.0 W PSE TLV Configured : dot3, MED
PD Requested Power Value : 0.0 W PSE TLV Sent Type : dot3
MED LLDP Detect : Enabled PD TLV Sent Type : dot3
LLDP Dual Signature Information
PSE Allocated Power Value A : 20.0 W PSE Allocated Power Value B : 20.0 W
PD Requested Power Value A : 20.0 W PD Requested Power Value B : 20.0 W
Power Information
PSE Voltage : 54.0 V PSE Reserved Power : 3.2 W
PD Amperage Draw : 57 mA PD Power Draw : 3.2 W
Example show command output at a port where LLDP is disabled.
Aruba-2930M-40G-8SR-PoE-Class6(slot 1)$ show pow 1
Status and Configuration Information for port 1
Power Enable : Yes PoE Port Status : Delivering
PLC Class/Type : 4/3 Priority Config : low
DLC Class/Type : 0/- Pre-std Detect : off
Alloc By Config : usage Configured Type :
Alloc By Actual : usage PoE Value Config : n/a
PoE Counter Information
Over Current Cnt : 0 MPS Absent Cnt : 0
Power Denied Cnt : 0 Short Cnt : 0
LLDP Information
PSE Allocated Power Value : 0.0 W PSE TLV Configured : MED
126 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
