Feature

Mirrors (MAC, VLAN, port)

PVST/RPVST/STP

DLDP

UDLD

LLDP/CDP

GVRP/MVRP

LACP

Uplink Failure Detection

sFlow

Loop protect

Smartlink

Global QoS (VLAN, port, rate limit)

MAC lockout/lockdown

ACL/Classifiers (ingress/egress)

IGMP/MLD

GMB

Broadcast-limit

Energy Efficient Ethernet

Flow Control

PoE

• poe-allocate-by

• poe-lldp-detect

Rogue MAC detection

LLDP auto provisioning

Restrictions

• Once a tunneled node profile is applied to a port, the controller IP (primary and backup) cannot be changed.

• IP address cannot be assigned to VLANs that contain ports with Port-Based Tunneling configured.

Chapter 18 Dynamic Segmentation 615
