4. Right-click IPv4 and select Set Predefined Options. Select option class as the newly defined vendor class,

click ADD and enter the following information for Proxy details:

a. Name - Proxy

b. Data Type - String

c. Code - 148

d. Description - Proxy details.

Chapter 10 Zero Touch Provisioning with AirWave and Central 339
