Entity Identity
Switch IP address 10.28.192.1
Document server IP address 10.28.229.219
With the above already configured, the following commands enable a DNS-compatible command with the host
name docserver to reach the document server at 10.28.229.219.
Configuring switch "A" in Example: network domain to support DNS resolution
switch(config)# ip dns server-address 10.28.229.10
switch(config)# ip dns domain-name pbs.outdoors.com
Ping and traceroute execution for the network in Example: network domain
switch(config)# ping docservr
10.28.229.219 is alive, time = 1 ms
switch# traceroute docservr
traceroute to 10.28.229.219
1 hop min, 30 hops max, 5 sec. timeout, 3 probes
1 10.28.192.2
1
1 ms 0 ms 0 ms
2 10.28.229.219
2
0 ms 0 ms 0 ms
•
1
First-Hop Router (“B”)
•
2
Traceroute Target
As mentioned under the following example, if the DNS entry configured in the switch does not include the domain
suffix for the desired target, you must use the target host's fully qualified domain name with DNS-compatible
commands. For example, using the document server in
Figure 99: Example: network domain on page 547 as a
target:
Figure 100: Example: of ping and traceroute execution when only the DNS server IP address is configured
548 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
