Status or
parameter
Description
Mode The port's speed and duplex (data transfer operation) setting.10/100/1000Base-T
Ports:
• Auto-MDIX (default): Senses speed and negotiates with the port at the other end of the
link for port operation (MDI-X or MDI).To see what the switch negotiates for the auto
setting, use the CLI show interfaces brief command.
• MDI: Sets the port to connect with a PC using a crossover cable (manual mode—applies
only to copper port switches using twisted-pair copper Ethernet cables)
• MDIX: Sets the port to connect with a PC using a straight-through cable (manual mode—
applies only to copper port switches using twisted-pair copper Ethernet cables)
• Auto-10: Allows the port to negotiate between half-duplex (HDx) and full-duplex (FDx)
while keeping speed at 10 Mbps. Also negotiates flow control (enabled or disabled).
Hewlett Packard Enterprise recommends auto-10 for links between 10/100 auto-sensing
ports connected with Cat 3 cabling. (Cat 5 cabling is required for 100 Mbps links.).
• 10HDx:10 Mbps, half-duplex
• 10FDx: 10 Mbps, full-duplex
• Auto-100: Uses 100 Mbps and negotiates with the port at the other end of the link for
other port operation features.
• Auto-10-100: Allows the port to establish a link with the port at the other end at either
10 Mbps or 100 Mbps, using the highest mutual speed and duplex mode available. Only
these speeds are allowed with this setting.
• Auto-1000: Uses 1000 Mbps and negotiates with the port at the other end of the link for
other port operation features.
• 100Hdx: Uses 100 Mbps, half-duplex.
• 100Fdx: Uses 100 Mbps, full-duplex
Gigabit Fiber-Optic Ports (Gigabit-SX, Gigabit-LX, and Gigabit-LH):
• 1000FDx: 1000 Mbps (1 Gbps), full-duplex only
• Auto (default): The port operates at 1000FDx and auto-negotiates flow control with the
device connected to the port.
Gigabit Copper Ports:
• 1000FDx: 1000 Mbps (1 Gbps), full-duplex only
• Auto (default): The port operates at 1000FDx and auto-negotiates flow control with the
device connected to the port.
Table Continued
