Telnet:

telnet ip-address [oobm]

TFTP:

copy tftp ... ip-address filename... [oobm]

SNTP:

[no] sntp server priority priority ip-address [oobm] [version]

TIMEP:

[no] ip timep [dhcp | manual ip-address | [oobm]]

RADIUS:

[no] radius-server host ip-address [oobm]

TACACS+:

[no] tacacs-server host ip-address [oobm]

DNS:

[no] ip dns server-address priority priority ip-address [oobm]

Syslog:

[no] logging ip-address [[control-descr] | [oobm]]

Ping:

ping [...] [source [ip-address | vlan-id | oobm]]

Traceroute:

traceroute [...][source [ip-address|vlan-id|oobm]] Management and Configuration Guide

Example

Figure 114: Example data center on page 745 shows setup and use of network OOBM using the commands

described above.

744 Aruba 2930F / 2930M Management and Configuration Guide

for ArubaOS-Switch 16.08
