NOTE: After you install snap-ins, restart ConsoleOne and MMC to show the new entries.
Example: Creating and Configuring Directory Objects for Use with iLO 2 Devices in
eDirectory
The following example demonstrates how to set up roles and HP devices in a company called
samplecorp, which consists of two regions: region1 and region2.
Assume that samplecorp has an enterprise directory arranged according to that in Figure 9-14.
Figure 9-14 Roles and Devices Example
Begin by creating organizational units in each region to contain iLO 2 devices and roles specific
to that region. In this example, two organizational units are created, roles and HP devices, in
each organizational unit (region1 and region2).
Creating Objects
To create iLO 2 objects, follow these steps:
1. Use the ConsoleOne snap-ins provided by HP to create iLO 2 objects in the HP devices
organizational unit for several iLO 2 devices.
Directory Services for eDirectory 195
