HP Integrity BL870c - Onboard Administrator Leds and Buttons

4
Enclosure Link-Up Port
1
OA/iLO Network Port
2
OA Bay 1
5
Enclosure Link-Down Port
3
OA Bay 2 (redundant if used)
Figure 2-2 shows the OA LEDs and buttons.
Figure 2-2 Onboard Administrator LEDs and Buttons
4
OA Health LED
1
OA UID LED
2
Enclosure UID LED
5
OA Reset Button
3
OA Active LED
