Figure 9-21 Lights-Out Management Device Rights Tab
Table 9-2 lists the available management device rights.
Table 9-2 Management Device Rights
DescriptionOption
This option controls whether users can log in to the associated devices and execute status
or read-only commands (view event logs and console logs, check system status, power
status, and so on) but not execute any commands that would alter the state of iLO 2 or the
system.
Login
This option enables users to access the system console (the host OS).Remote Console
This option enables users to connect devices through the network such as CD, DVD, and
network drives as virtual devices.
Virtual Media
This option enables users to execute iLO 2 power operations to remotely power on, power
off, or reset the host platform, as well as configure the system's power restore policy.
Server Reset and Power
This option enables users to administer local iLO 2 user accounts.Administer Local User
Accounts
This option enables users to configure all iLO 2 settings, as well as reboot iLO 2.Administer Local Device
Settings
Installing Snap-Ins and Extending Schema for eDirectory on a Linux Platform
This section describes a method that does not require a Windows client to install snap-ins and
extend schema for eDirectory on a Linux platform.
Schema extension is the addition of new classes to existing classes. You can use these classes to
create objects to support a specific utility. New classes are added, such as hpqTarget, hpqPolicy
and hpq role. HP has created objects using these classes to support iLO 2 devices (created using
the hpqTarget class), and iLO 2 admins and monitors (created using the hpqRole class). These
objects support the Login Authentication utility to the iLO 2 device and enable iLO 2 users to
execute commands based on their assigned roles.
Installing the Java Runtime Environment
As a prerequisite for extending schema, you must have Java Runtime Environment (JRE) 1.4.2
installed.
Directory Services for eDirectory 201
